Program to format IEEE-754 binary 64 bit format

This program takes an decimal number from the command line and formats it in the IEEE-754 binary 64 bit format. It outputs various data a long the way showing information about the process. The formatted data is placed in a "long integer" which is part a union. Which contains a "double" of the same size. At the end of the program the "double" is out to verify the format.

To Compile:

        clang -o formatF2b -lm formatF2b.c


        gcc -o formatF2b -lm formatF2b.c


Convertion Demo Code

     1	///////////////////////////////////////////////////////////////////////
     2	//
     3	// formatF2b.c
     4	//
     5	// Written by: Don Dugger
     6	//       Date: 2024-01-06
     7	//
     8	// Copyright (C) 2024 Acme Software Works, Inc.
     9	//
    10	// Redistribution and use in source and binary forms, with or without
    11	// modification, are permitted provided that the following conditions are met:
    12	//
    13	// 1. Redistributions of source code must retain the above copyright notice,
    14	//    this list of conditions and the following disclaimer.
    15	//
    16	// 2. Redistributions in binary form must reproduce the above copyright notice,
    17	//    this list of conditions and the following disclaimer in the documentation
    18	//    and/or other materials provided with the distribution.
    19	//
    20	// THIS SOFTWARE IS PROVIDED BY THE COPYRIGHT HOLDERS AND CONTRIBUTORS "AS IS"
    21	// AND ANY EXPRESS OR IMPLIED WARRANTIES, INCLUDING, BUT NOT LIMITED TO, THE
    22	// IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE
    23	// ARE DISCLAIMED. IN NO EVENT SHALL THE COPYRIGHT HOLDER OR CONTRIBUTORS BE
    24	// LIABLE FOR ANY DIRECT, INDIRECT, INCIDENTAL, SPECIAL, EXEMPLARY, OR
    25	// CONSEQUENTIAL DAMAGES (INCLUDING, BUT NOT LIMITED TO, PROCUREMENT OF SUBSTITUTE
    26	// GOODS OR SERVICES; LOSS OF USE, DATA, OR PROFITS; OR BUSINESS INTERRUPTION)
    27	// HOWEVER CAUSED AND ON ANY THEORY OF LIABILITY, WHETHER IN CONTRACT, STRICT
    28	// LIABILITY, OR TORT (INCLUDING NEGLIGENCE OR OTHERWISE) ARISING IN ANY WAY OUT
    29	// OF THE USE OF THIS SOFTWARE, EVEN IF ADVISED OF THE POSSIBILITY OF SUCH DAMAGE.
    30	//
    31	///////////////////////////////////////////////////////////////////////
    32
    33	#include <stdio.h>
    34	#include <stdlib.h>
    35	#include <assert.h>
    36	#include <stdint.h>
    37	#include <unistd.h>
    38	#include <libgen.h>
    39	#include <stdbool.h>
    40	#include <math.h>
    41
    42	///////////////////////////////////////////////////////////////////////
    43
    44	long fraction2bin(double decimal, int size);
    45
    46	///////////////////////////////////////////////////////////////////////
    47
    48	#define FORMAT_SIZE   64
    49	#define MANTISSA_SIZE 52
    50	// The BIAS is (2^(number bits of the exponent))/2 - 1
    51	#define BIAS          1023
    52
    53	///////////////////////////////////////////////////////////////////////
    54	///
    55	///  main
    56	///
    57	///  @brief  This program takes an decimal number from the command line
    58	///          and formats it in the IEEE-754 binary 64 bit format.
    59	///          It outputs various data a long the way showing information
    60	///          about the process.
    61	///          The formatted data is placed in a "long integer" which is
    62	///          part a union. Which contains a "double" of the same size.
    63	///          At the end of the program the "double" is out to verify
    64	///          the format.
    65	///
    66	///  @return Zero
    67	///
    68	///////////////////////////////////////////////////////////////////////
    69	///
    70	int main(int argc, char* argv[])
    71	{
    72	    /// This union is used to verify the result
    73	    union {
    74	        double f;
    75	        long i;
    76	    } u;
    77	    ///////////////////////////////////////////////////////////////////
    78	    /// Get the floating point number that will be formatted
    79	    char* end;
    80	    double original = strtod(argv[1],&end);
    81
    82	    ///////////////////////////////////////////////////////////////////
    83	    /// Check the sign of the input and remove it form the input
    84	    bool negative = false;
    85	    if (original < 0) {
    86	        negative = true;
    87	        original *= -1;
    88	    }
    89
    90	    ///////////////////////////////////////////////////////////////////
    91	    /// Extract the integer portion and fraction of the input
    92	    double integer;
    93	    double fraction = modf(original,&integer);
    94	    long int_portion = (long)integer;
    95
    96	    ///////////////////////////////////////////////////////////////////
    97	    /// Determine the exponent
    98	    long exponent = 0;
    99	    if ( int_portion == 0 ) {
   100	        /// If the input is less than one, the exponent will be a
   101	        /// negative number. In that case, negative exponents will
   102	        /// be tested until it is greater than the fraction. Which
   103	        /// is one greater than the proper exponent. The negative
   104	        /// exponent can not be greater than the BIAS, so that
   105	        /// will be the last exponent tested.
   106	        for (int idx=0;idx>-BIAS;--idx) {
   107	            if ( pow(2,idx) > fraction) {
   108	                exponent = idx-1;
   109	            }
   110	        }
   111	    } else {
   112	        /// If the input is one or greater, the exponent will be
   113	        /// positive. And in that case the exponent is determined
   114	        /// by the position of the most significant one in the
   115	        /// binary integer portion of the input. So when 2 to the
   116	        /// power of "idx" is greater the integer portion of the
   117	        /// input. The most significant one is one less.
   118	        for (int idx=0; idx<=BIAS && exponent == 0; ++idx) {
   119	            if ( int_portion < pow(2,idx)) {
   120	                exponent = idx-1;
   121	            }
   122	        }
   123	    }
   124
   125	    ///////////////////////////////////////////////////////////////////
   126	    /// Determine the mantissa
   127	    ///  The mantissa times two raised to the exponent is the way the
   128	    ///  formatted floating point will be evaluated. So reversing the
   129	    ///  process will yield the mantissa.
   130	    double mantissa = original / pow(2,exponent);
   131
   132	    ///////////////////////////////////////////////////////////////////
   133	    /// Now output the result.
   134	    printf("Exponent = %ld\n",exponent);
   135	    printf("Integer  = %ld\n",int_portion);
   136	    printf("Fraction = %lf\n",fraction);
   137	    printf("Mantissa = %lf\n",mantissa);
   138
   139	    ///////////////////////////////////////////////////////////////////
   140	    /// Now place the results in the integer element of the union to
   141	    /// verify the results.
   142	    long bin_exp = ((exponent + BIAS) & ((BIAS*2)+1));
   143	    printf("==============================\n");
   144	    printf("Sign            = %d\n", negative ? 1 : 0);
   145	    // For the 64 bit format the exponent is 11 bits
   146	    printf("Binary Exponent = %11.11b\n",(int)bin_exp);
   147	    u.i = fraction2bin(mantissa,MANTISSA_SIZE);
   148	    printf("Binary Mantissa = ");
   149	    for (long idx = MANTISSA_SIZE-1;idx>=0;--idx) {
   150	        printf("%d", (((long)1 << idx) & u.i) ? 1 : 0);
   151	    }
   152	    printf("\n");
   153	    bin_exp <<= MANTISSA_SIZE;
   154	    u.i |= bin_exp;
   155	    if ( negative ) {
   156	        u.i |= (long)pow(2,FORMAT_SIZE-1);
   157	    }
   158	    printf("==============================\n");
   159	    printf("Results = %lf\n",u.f);
   160
   161	    return 0;
   162
   163	} // End of main()
   164
   165	///////////////////////////////////////////////////////////////////////
   166	///
   167	/// @Brief This is a basic decimal fraction to binary fraction
   168	///        converter.
   169	///        The algorithm works by first removing the integer
   170	///        portion of the decimal number and then multiplying
   171	///        the fraction by two and if the result is greater than
   172	///        one setting the bit in the binary result to one then
   173	///        move to the next bit. Then repeating the process until
   174	///        it reaches size requested. It starts at the most
   175	///        significant bit of the output and working it's way
   176	///        down to the least significant bit.
   177	///
   178	/// @Param The decimal with the one in place.
   179	/// @Param The size of the binary fraction.
   180	///
   181	/// @return The binary fraction.
   182	///
   183	///////////////////////////////////////////////////////////////////////
   184	///
   185	long fraction2bin(double fraction, int size)
   186	{
   187	    //double f = fraction - 1;
   188	    double integer;
   189	    long bin = 0;
   190	    long pos = 1;
   191	    fraction = modf(fraction,&integer);
   192	    pos <<= (size-1);
   193	    for (int idx=0;idx<=size;++idx) {
   194	        fraction *= 2;
   195	        if ( fraction >= 1.0 ) {
   196	            bin |= pos;
   197	            fraction -= 1.0;
   198	        }
   199	        pos >>= 1;
   200	    }
   201
   202	    return bin;
   203	} // End of fraction2bin()
   204
   205	///////////////////////////////////////////////////////////////////////
   206	//////////////////////// End of File //////////////////////////////////
   207	///////////////////////////////////////////////////////////////////////
